Pro.2 HDMI 1X2 Splitter or 2X1 Switch Bandwidth 18Gbps Down Scaler Function

1 in 2 out HDMI splitter OR 2 in 1 out HDMI switch via the function button whenever required. HDMI 2.0 specification, up to 18Gbps bandwidth, analog 3.5mm stereo and SPDIF audio extractor or embedder, all built into this compact HDMI2SPW.

• HDMI 2.0 version
• Support 4K@60Hz YUV4:4:4
• Bandwidth up to 18Gbps
• HDCP2.2/HDCP1.4
• Support 3D, HDR10, Dolby Vision, and DTS
• Support 2x HDMI in, 2x HDMI out
• EDID management
• Down scaler function
• Support analog 3.5mm stereo/SPDIF audio extraction
• Support analog 3.5mm stereo/SPDIF audio embedded
• Support power-off memory function

• Operating Temperature Range: 0°C to +40°C(+32°f to + 104 °f )
• Operating Humidity Range: 5 to 90%RH (No Condensation)
• Power supply: 5V 1A
• Maximum power: 2W (work under 4K2K/60hz)
• Max resolution: 4k@60hz YUV4:4:4
• Function: HDR10 and Dolby vision
• HDMI version: HDMI2.0
• Bandwidth: 18Gbps
• HDCP version: HDCP2.2/HDCP1.4
• Control ways: Switch button and EDID
• Distance: 1080P: input 8m max; output 8m max, 4k@30hz: input 8m max;output 8m max, 4k@60hz-8bit: input 5m max;output 5m max
• Dimensions(LxWxH): 121 x68.2x20mm
