QNAP TS-653D-4G 6-Bay NAS Server, Quad Core Celeron J4125 2GHz, 4GB RAM, 2x 2.5GbE LAN, PCIe Expansion Slot for SSD Cash or 10GB , Ethernet Port, 2x USB3.2 Gen1, 1x HDMI 2.0, 3 Years Warranty



QNAP 6-Bay Diskless NAS
The new-gen Wi-Fi 6 (802.11ax) trend has driven higher bandwidth demands for wired and wireless network connections. By integrating Intel® Celeron® J4125 quad-core 2.0 GHz processor and 2.5GbE connectivity, the TS-653D not only provides modern businesses an excellent NAS solution to upgrade to 2.5GbE environments for productive daily backup/restore tasks, but also provides gamers with ample storage for their vast game collections. Up to 5 Gbps transfer speeds can be made by setting port trunking with the two built-in 2.5GbE ports. The TS-653D also supports PCIe expansion, multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS.
- Dual 2.5GbE ports accelerates file sharing across teams and devices or gaming storage applications.


- PCIe expansion allows for a Multi-Gig 10GbE or 5GbE network card, or a QM2 card to add M.2 NVMe or SATA SSDs for caching.


- 4K media playback and real-time transcoding; directly watch videos on an HDTV via HDMI 2.0 (4K @60Hz) output.


- HBS provides comprehensive backup and data recovery; QuDedup deduplicates the data at the source to reduce storage space usage, bandwidth usage, and backup time.


- Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud.


- Hosts multiple virtual machines and containers to execute different applications in one NAS device.


Upgrade your NAS to 2.5GbE networks
The TS-653D comes with two 2.5GbE RJ45 LAN ports that allow you to use existing CAT5e cables to upgrade network speeds from 1 Gigabit to 2.5 Gigabit. The dual 2.5GbE ports also support Port Trunking for up to 5 Gbps! By using QNAP's N-BASET/Multi-Gig USB 3.2 Gen 1 to 5GbE adapter (Model name QNA-UC5G1T) or 5GbE PCIe expansion card (Model name QXG-5G1T-111C), your laptop or desktop computer can easily connect to 2.5GbE networks with the TS-653D to benefit from higher network speeds.
Virtualization - Satisfies bandwidth-demanding applications such as virtual machines and containers.


Video Streaming - Boosts transfer speeds to improve smooth 4K video streaming and display.


Gaming Storage - Mount an iSCSI LUN from the TS-653D to your computer to store your vast game collections.


Transform your network with a wallet-friendly 2.5GbE switch
Upgrading your network shouldn't break the bank, and 2.5GbE connectivity provides immediately noticeable improvements compared to standard 1GbE. The QSW-1105-5T is an unmanaged switch with five 2.5GbE ports (backwards compatible with 1G/100M) and supports CAT5e cables to connect multiple computers and NAS. The QSW-1105-5T is energy-saving, low-noise, plug-and-use, and supports loop detection and blocking to provide a simple and effective high-speed network environment.


Quad-core 2.0 GHz (burst up to 2.7 GHz) with up to 8 GB memory
The TS-653D is powered by an Intel® Celeron® J4125 quad-core 2.0 GHz processor (bursts up to 2.7 GHz), features up to 8 GB DDR4 memory, and supports SATA 6 Gb/s drives. The support of Intel® AES-NI encryption engine boosts encryption performance while also maintaining the security of your NAS data. You can flexibly install SSDs for cache acceleration to maximize network and storage performance for data-intensive applications.
Tested in QNAP Labs. Figures may vary by environment.
Test environment:
NAS: TS-653D-4G
OS: QTS 4.4.2
Volume type:
6 x Samsung 850 Pro 512GB SSDs, RAID 5, thick volume
Client PC:
Windows 10 Pro, Intel Core i7-6700 3.4 GHz, 32GB RAM, 10GB file transfer
IOmeter:
RAM*4, 30-sec ramp up time, 3-min seq. run time, 4 workers, 64-outstanding
- Windows File Transfer (1 x 2.5GbE, 10GB file)


- Windows Sequential File Transfer (2 x 2.5GbE, 1MB)


- Windows File Transfer (1 x 10GbE, 10GB File)


Virtualization Certifications Supported by TS-653D
Check QNAP NAS with Support for Virtualization application


A secure data center for backing up device data with snapshot protection
Windows® and Mac® backup - Use the license-free QNAP NetBak Replicator utility to back up and restore files from Windows® computers. Apple's Time Machine® is supported for backing up Mac® computers.

Snapshots for Volume & LUN - Snapshots are essential for NAS data protection, and their block-level feature makes it a dependable data protection method in the face of growing ransomware threats. The TS-653D supports up to 256 snapshots per volume/LUN, and up to 1,024 snapshots per NAS.


One 2.5GbE is better than two 1GbE for increasing HBS backup efficiency
With a single 2.5GbE connection, no complex link aggregation settings are required for speeds up to 312.5MB/s - easily beating a paired 1GbE connection. The TS-653D has two 2.5GbE ports, further doubling performance and increasing efficiency for versatile tasks.
Hybrid Backup Sync (HBS) consolidates backup and synchronization functions for easily transferring data from the TS-653D to local, remote and cloud storage spaces. HBS also supports QuDedup technology which removes duplicated data at the source, further accelerating backup and restoration tasks over 2.5GbE connections.

Abundant I/O capability with PCIe expansion
The TS-653D features one PCIe 2.0 slot that allows for various expansion cards for expanding application potential.
Wireless adapter - Turn your NAS into a wireless access point or a base station by installing a QNAP QWA-AC2600 wireless adapter and the WirelessAP Station app.


5GbE/10GbE network card - Enable lightning-fast throughput for bandwidth-demanding tasks, such as virtualization, massive data transmission, and fast backup/restoration.


QM2 M.2 SSD/10GbE card - Adds M.2 SSD caching or 10GbE (10GBASE-T) connectivity to the NAS for optimized performance and bandwidth.


Wi-Fi 6 wireless adapter - Install a PCIe 802.11AX network adapter (based on the Intel® AX200) in your NAS to create a seamless Wi-Fi 6 network environment.


SSD caching and auto-tiering enable 24/7 optimized storage efficiency
While SSD prices continue to fall, and SSD capacity and performance continue to increase, organizations can easily take advantage of SSD strengths. The TS-653D supports numerous SSD-aware features that significantly maximize NAS performance with high cost-effectiveness.

Ultimate visual experience with 4K HDMI display and real-time video transcoding
The TS-653D has an HDMI 2.0 port that supports 4K (4096 x 2160) 60Hz output, allowing you to directly view multimedia content saved on the NAS on a bigger screen. The support of high-quality 4K video transcoding enables the NAS to convert videos to universal file formats that can be smoothly played on multiple devices. The TS-653D also can stream videos through DLNA®, Chromecast™, and more to satisfy versatile multimedia application needs. The QNAP RM-IR004 remote control (sold separately) can be configured using QButton to customize individual button actions, providing a more user-friendly NAS experience.

Note: The TS-653D's hardware provides hardware decoding, encoding, and transcoding capabilities. However, playback quality may vary due to factors including playback software, file formats, system usage, and available bandwidth.

Build a Plex Media Server
By installing Plex® Media Server from App Center, setting up the Plex® Media Server on your NAS is only a few minutes away. You can stream media files stored on the TS-653D to mobiles and media streaming devices (including DLNA®, Roku®, Amazon Fire TV® and Google Chromecast™).

Note: PlexPass is required for Plex Media Server hardware transcoding.

Package contents



For more information: https://www.qnap.com/en/product/ts-653d

CPU
Intel® Celeron® J4125 4-core/4-thread processor, burst up to 2.7 GHz
CPU Architecture
64-bit x86
Graphic Processors
Intel® HD Graphics 600
Floating Point Unit
Yes
Encryption Engine
Yes (AES-NI)
Hardware-accelerated Transcoding
Yes
System Memory
8 GB SO-DIMM DDR4 (2 x 4 GB)
Maximum Memory
8 GB (2 x 4 GB)
Memory Slot
2 x SO-DIMM DDR4
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
Flash Memory
4 GB (Dual boot OS protection)
Drive Bay
6 x 3.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/
Drive Compatibility
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
Yes
M.2 Slot
Optional via a PCIe adapter
SSD Cache Acceleration Support
Yes
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2 (also support 10M)
5 Gigabit Ethernet Port (5G/2.5G/1G/100M)
Optional via PCIe expansion card
10 Gigabit Ethernet Port
Optional via PCIe expansion card
Optional via PCIe expansion card
Wake on LAN (WOL)
Yes - Only the 2.5GbE port
Jumbo Frame
Yes
PCIe Slot
1
Slot 1: PCIe Gen 2 x2
PCIe bandwidth limitations will restrict the NAS 10GbE performance.
USB 2.0 port
3
USB 3.2 Gen 1 port
2
USB 3.2 Gen 2 (10Gbps) Port
Optional via a PCIe adapter
IR Sensor
Yes(Optional QNAP RM-IR004 remote control)
HDMI Output
1, HDMI 2.0 (up to 4096 x 2160 @ 60Hz)
Form Factor
Tower
LED Indicators
Power/Status, LAN, USB, HDD1-6
Buttons
Power, USB copy, Reset
Dimensions (HxWxD)
168 × 235 × 226 mm
Weight (Net)
2.9 kg
Weight (Gross)
4.56 kg
Operating temperature
0 ~ 40°C (32°F ~ 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27°C (80.6°F)
Power Supply Unit
120W adapter, 100-240V
Power Consumption: HDD Sleep Mode
18.634 W
Power Consumption: Operating Mode, Typical
35.437 W
Tested with drives fully populated.
Fan
2 x 90mm, 12VDC
Sound Level
21.3 db(A)
System Warning
Buzzer
Kensington Security Slot
Yes
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
1500

GTIN: 885022019069

Reference ID: 6770389
