Desktop 10G Cloud Gateway with integrated 4-port 2.5 GbE switch, NVR storage slot, and full UniFi application support.
Features:
UniFi routing and cybersecurity in a strikingly compact form factor. Site Manager ready with multi-WAN load balancing and full IPS security.
Completely plug-and-play with no CloudKey required. Just add internet.
Equipped with a built-in 4-port 2.5 GbE switch, including one PoE+ port, the Cloud Gateway Fiber simplifies device connectivity and power management.
Featuring both a 10G SFP+ and a 10 GbE RJ45 WAN port, the Cloud Gateway Fiber offers versatile high-speed internet connection options.
Designed with a sleek and compact desktop form factor, the Cloud Gateway Fiber fits neatly into various environments without occupying excessive space.
Manage 50+ UniFi devices and 500+ connected clients through a single interface.
The complete UniFi experience in a strikingly compact form factor.
Overview
|
|
---|---|
Dimensions | 212.8 x 127.6 x 30 mm (8.3 x 5 x 0.5 ") |
UniFi Application Suite | |
Network | ✓ |
Protect | ✓ |
Access | ✓ |
Talk | ✓ |
Connect | ✓ |
Managed UniFi Devices | 50+ |
Managed Cameras | (15) HD (8) 2K (5) 4K |
Simultaneous Users Connected | 500+ |
Max. WAN Port Count | 6 |
Default WAN Ports | (1) 10G SFP+ (1) 10 GbE RJ45 |
Port Layout | |
2.5 GbE RJ45 | 4 (2.5G/1G/100M/10M) |
10 GbE RJ45 | 1 (10G/2.5G/1G) |
10G SFP+ | 2 (10G/1G) |
IDS/IPS Throughput | 5 Gbps |
Form Factor | Compact desktop |
Security
|
|
Stateful Firewall | ✓ |
Application-Aware Layer 7 Firewall | ✓ |
DPI & Traffic Identification | ✓ |
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) | ✓ |
Content Filtering | ✓ |
Intrusion Prevention (IPS/IDS) | ✓ |
Ad Blocking | ✓ |
IDS/IPS Signatures | 55,000+ with CyberSecure |
VLAN/Subnet-based Traffic Segmentation | ✓ |
VPN &SD-WAN
|
|
License-Free SD-WAN | ✓ |
Site-to-Site VPN | |
Site Magic | ✓ |
IPsec | ✓ |
OpenVPN | ✓ |
VPN Server | |
Identity Endpoint One-Click VPN | ✓ |
Teleport Zero-Configuration VPN | ✓ |
WireGuard | ✓ |
OpenVPN | ✓ |
L2TP | ✓ |
VPN Client | |
OpenVPN | ✓ |
WireGuard | ✓ |
Networking
|
|
Multi-WAN Load Balancing | ✓ |
Dynamic Routing | |
OSPF | ✓ |
Advanced QoS | ✓ |
Multicast DNS (mDNS) | ✓ |
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) | ✓ |
Integrated RADIUS Server | ✓ |
RADIUS over TLS (RadSec) | ✓ |
Additional Internet Failover with UniFi LTE Backup | ✓ |
Internet Quality and Outage Reporting | ✓ |
MAC Address Table Size | 4000 |
Hardware
|
|
NVR Storage | Selectable NVMe SSD up to 2 TB |
PoE Budget | 30W |
Voltage Range PoE Mode | 50-57V |
Max. Power Consumption | 29.4W (Excluding PoE output) |
Power Method | DC jack (54V DC/1.1A) |
Power Supply | 54V DC/1.1A (adapter included) |
Supported Voltage Range | 100240V AC |
Processor | Quad-core ARM® Cortex®-A73 at 2.2 GHz |
System Memory | 3 GB |
Weight | Without SSD: 675 g (1.5 lb) With SSD: 734 g (1.6 lb) |
Enclosure Material | Polycarbonate |
LCM Display | 0.96" status display |
Management | Ethernet Bluetooth |
LEDs | |
Ethernet | ✓ |
SFP+ | ✓ |
Button | (1) Factory-reset |
ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV |
Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
Ambient Operating Humidity | 5 to 95% noncondensing |
NDAA Complied | ✓ |
Certifications | CE, FCC, IC |
