KRAMER Yarden 8-T 8" Kevlar 70/100V In-Ceiling Tile Stereo Speaker Single

Image 1
Image 2
Image 3
Hurry! 7 items left!
$299

Collect 299 Everyday Rewards points

Log in to MyDeal to link your card
Free Shipping

Dispatch in 2 business days

Sold & shipped by Precision Audio
Secure ways to pay at checkout
The Yarden 8−T High−Performance Ceiling Tile Stereo Speaker features a Kevlar(R) woofer, four pivoting titanium tweeters, complete K−overage ESD™ (Equal Sound Dispersion) design for almost 180 degrees of sound dispersion. It features speech mode to improve intelligibility, music mode for an extra wide frequency response and stereo and mono modes to fit any kind of installation. It also features a magnetically held grill (with two security screws) for time saving installation, 2nd level cross−over design and multi−tap power transformer for selecting 8Ω (bypassing the transformer) or 70V/100V power settings that are suitable for an array installation.
  • Type — 2–way ceiling tile speaker.
  • Woofer — 8” Kevlar(R) cone.
  • Tweeters — Four pivoting 0.75” titanium domes.
  • Impedance — Stereo 8Ω, mono 4Ω.
  • Stereo/Mono Selector Switch.
  • Speech/Music Selector Switch.
  • Power Handling — 2 x 40W RMS, 2 x 110W continuous program.
  • Transformer Taps — Stereo: 70V: 2 x 30W/15W/7.5W/3.7W, 100V: 2 x 30W/15W/7.5W; Mono: 70V: 60W/30W/15W/7.5W, 100V: 60W/30W/15W.
  • UL Certification — UL 1480 & 2043 listed and plenum compliant.
  • Package — 1 speaker.

  • FREQUENCY RESPONSE: 65Hz to 20kHz @–10dB, 80Hz to 20kHz @±3dB
  • WOOFER: 8” (200mm) Kevlar(R) with rubber surround
  • TWEETER: Four 0.75” (20mm) pivoting titanium domes
  • IMPEDANCE: 8Ω stereo, 4Ω mono (transformer tap in off position)
  • TRANSFORMER TAPS: Stereo: 70V — 3.75W/7.5W/15W/30W
  • 100V — 7.5W/15W/30W, Mono: 70V — 7.5W/15W/30W/60W
  • 100V — 15W/30W/60W
  • SENSITIVITY: 87dB 1W @1m
  • MAX SPL: Continuous: 102dB, peak: 105dB
  • POWER HANDLING: 40W RMS, 110W continuous program
  • CROSSOVER FREQUENCY: 2.175kHz
  • DIRECTIVITY FACTOR (Q): 9.43 averaged 1kHz to 10kHz
  • DIRECTIVITY INDEX (DI): 9.5dB averaged 1kHz to 10kHz
  • INPUT CONNECTORS: Terminal block connectors
  • CONTROLS: Mono/Stereo select switch, Music/Speech select switch
  • MATERIALS: Frame, steel grills (595x595mm, 605x605mm), cable holder
  • OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)
  • STORAGE TEMPERATURE: –40° to +70°C (–40° to 158°F)
  • HUMIDITY: 10% to 90%, RHL non–condensing







          GTIN: 0748322102056

          Estimated Delivery Time Frame:2 - 7 Business Days

          Ask a Question About This Product

          Reference ID: 10465899
