Invicta 24V 12Ah Lithium Battery with 4 Series Functionality

Invicta 24V 12Ah Lithium Battery with 4 Series Functionality

Price	$419
	Collect 419 Everyday Rewards points Log in to MyDeal to link your card
Shipping	Free shipping to select areas Unable to calculate delivery for , please Contact Us Delivery unavailable to Change
	24-48 hour dispatch See delivery details

Quantity

Add to wishlist

Invicta 24V 12Ah Lithium Battery with 4 Series Functionality

Invicta lithium batteries are available in over 20 12V, 24V and 36V sizes that consist of aluminum encased prismatic cells which have been bolted together using solid busbar connectors. These have been further reinforced with a strengthening frame to resist damaging vibrations.

Invicta lithium batteries are designed to the highest specifications to deliver a premium solution that has been proven to perform. Consisting of high-grade aluminium Lithium Iron Phosphate (LiFePO4) prismatic cells, solid busbar connectors and an integrated BMS, Invicta lithium batteries are a reliable and robust deep-cycle battery for those that need complete confidence in their system.

The integrated BMS has been engineered for the Australian market and is a robust component that provides automated protection against overcharge/discharge, temperature, short circuit, which can be monitored with Bluetooth models.

All Invicta Lithium batteries have undergone IEC62133/UL1642 certification on a cell level with selected models also achieving IEC62619 on the entire battery and BMS. This testing guarantees the performance and safety of the cells and battery in high-stress environments.

Features:

7-year warranty and IEC Certification
Aluminium-encased prismatic cells
Integrated BMS with automatic protections
Wireless monitoring (Bluetooth range only)
Bolted busbar intercell connectors
Slimline and standard AGM case sizes
Strengthening frame to resist damaging vibrations
2000+ genuine cycles @ 100% DoD
Australia’s widest range of 12V, 24V, 36V & 48V single battery solutions
Independently tested in Australia
Safe Lithium Iron Phosphate (LiFePO4) chemistry
Automatic BMS battery protection (overcharge/discharge, temperature, short circuit and)
Can be installed on either of their sides (not upside down)
Less than half the weight
Faster recharge
More efficient use of capacity
Can sit unused for up to 12 months
2 x more runtime
Up to 10 years life

Specifications:

Nominal Voltage: 25.6.8V
Nominal Capacity (250C, 0.33C): 12Ah
Terminal: M6
Battery Length (mm): 166 ± 2mm
Battery Width (mm): 176 ± 2mm
Battery Height (mm): 125 ± 2mm
Battery Weight: 3.40kg
Max Charge Voltage: 29.2 ± 0.1V
Standby: 27.8 ± 0.1V
Cut off Voltage: 20V
Max. Discharge Current: 10A
Max. Pulse Discharge Current (3 Sec): 60A
Max. Charge Current: 10A
Recommended Current Charge: ≤6A
Cycle Life (100% DoD): >2000
Operating Temp - Charge: 0 - 500C
Operating Temp - Discharge: -20 - 550C
Short Circuit Release: Load Release
Max. Series / Parallel Configuration: 4P

SKU: SNL24V12
